Chapter 3
A55F-M4 USER MANUAL
33
Smart Fan Start offset(-) (37)
StartUp Value (102)
This item is used to set the start temperature of the smart fan.
This item specifies the start PWM of the smart fan when the temperature is be-
tween the start temperature plus tolerance value and start temperature minus
tolerance value.
Tolerance Value (3)
This item specifies the temperature tolerance value of the smart fan.
Stop value (77)
This item specifies the PWM of the smart fan when the temperature is lower than
the start temperature minus tolerance value.
Press <Esc> to return to the PC Health Status page.
• CPU Tct1
• CPU Fan Speed
• System Fan Speed
• CPU Voltage
• DIMM Voltage
• FCH Voltage
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System temperature, CPU & DIMM voltage, CPU & System fan speed... etc.
Press <Esc> to return to the Advanced Menu page.
