ECS A55F-M4 User Manual

57
A55F-M4 USER MANUAL
Chapter 5
Chapter 5
CrossFire
TM
Technology (AMD Dual Graphics) Support
CrossFire
TM
Technology
The CrossFire
TM
technology provides significant display performance boost to AMD-
based systems by inserting the external PCI Express graphics card and enabling
both the discrete GPU and the AMD A55 graphics core to render simultaneously in
CrossFire
TM
mode.
Follow the steps below to start the CrossFire
TM
technology.
1. Insert a graphics card (which can be used for CrossFire
TM
technology, such as
HD6670 series) into the PCIEX16 slot.
Make sure that the card is properly seated on the slot.
2. For CrossFire
TM
, you must enter the BIOS, set the Initate Graphic Adapter in Ad-
vanced Menu to IGD. Then press F4 to save the configuration and exit the BIOS.
* For reference only
IGD Share Memory Size
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
/Click: Select Item
North Bridge
IGD Memory Auto
Initate Graphic Adapter IGD
CrossFire Enabled
