A55F-M4 USER MANUAL
Chapter 5
3. Set the CrossFire in Advanced Menu to Enabled. Then press F4 to save the configu-
ration and exit the BIOS.
4. Click with your right mouse button on My Computer, then click the option Manage
and choose the Device Manager, finally, click the Display Adapters. The following
screen appears. Be sure that the External ATI graphics (ATI Radeon HD 6670) and
Onboard graphics (Radeon HD 6530D or HD6550D) are both displaying in the Display
adapters.
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
/Click: Select Item
North Bridge
IGD Memory Auto
Initate Graphic Adapter IGD
CrossFire Enabled
CrossFire: Output is
IGD Video
