ECS A55F2-M3

Chapter 3
A55F2-M3 USER MANUAL
36
SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Mode (IDE Mode)
Use this item to select SATA mode.
SATA Port1~4 (INTEL SSDSC2CW(60.0GB/Not Present)
This motherboard supports four SATA channels, each channel allows one SATA device
to be installed. Use these items to configure each device on the SATA/mSATA chan-
nel.
Main Advanced Chipset M.I.B III Boot Security Exit
SATA Configuration
Serial-ATA Controller Enabled
SATA Mode IDE Mode
SATA Port1 INTEL SSDSC2CW (60.OGB
SATA Port2 Not Present
SATA Port3 Not Present
SATA Port4 Not Present
Press <Esc> to return to the Advanced Menu page.
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Serial-ATA Controller (Enabled)
Use this item to select Serial-ATA controller options: Disabled, Compatible, En-
hanced.
