USB Flash Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB Flash drive.
USB CD/DVD Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB CD/DVD drive.
USB HardDisk Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB HardDisk drive.
CD/DVD Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing CD/DVD drive.
USB/Floppy Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB/Floppy drive.
This page enables you to set the keyboard NumLock state.
Boot Menu
Main Advanced Chipset M.I.B III Boot Security Exit
Select the keyboard
NumLock state
USB CD/DVD
USB Hard Disk
USB Flash
Network
USB/Floppy
CD/DVD
UEFI
Boot Configuration
Bootup NumLock State On
Set Boot Priority
1st Boot Hard Disk: INTEL SS...
2nd Boot
3rd Boot
4th Boot
5thBoot
6thBoot
7th Boot
8th Boot
Hard Disk Drive Priorities [Press Enter]
CD/DVD Drive Priorities [Press Enter]
USB/Floppy Drive Priorities [Press Enter]
USB CD/DVD Drive Priorities [Press Enter]
USB HardDisk Drive Priorities [Press Enter]
USB Flash Drive Priorities [Press Enter]
NETWORK Device Priorities [Press Enter]
UEFI Boot Drive Priorities [Press Enter]
Bootup NumLock State (On)
This item enables you to select NumLock state.
1st/2nd/3rd/4th/5th/6th/7th/8th Boot
These items show the boot priorities.
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Hard Disk Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing hard disk drive.

ECS A55F2-M3 Specifications

General

Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1333, 1600, 1666 MHz
Supported memory module capacities	16GB, 2GB, 4GB, 8GB
Processor socket	Socket FM2
Processor manufacturer	AMD
Compatible processor series	AMD A
Maximum number of SMP processors	1
Power fan connector	Yes
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
HDMI ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	CE/FCC, WHQL, WHCK, ErP/EuP
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A55
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
RAID levels	0, 1, 10
Supported storage drive interfaces	SATA II
PCI Express slots version	2.0
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	180 mm
Width	230 mm
