ECS A785GM-AD3 User Manual

14
Installing the Motherboard
Type Size Vendor Module Name
A-data AD3U1333B1G9-B
Apacer 78.01GC6.9L0
Hynix HMT112U6AFP8C-H9N0 AA
FLFD45F-B8KG9 NAES
FLFD45F-B8KG9 NAUS
Kingston KVR1333D3N9/1G
Micron MT8JTF12864AY-1G4D1
PSC AL7F8G73D-DG1
Ramaxel RMR1810KD48E7F-1333
M378B2873DZ1-CH9
M378B2873EH1-CH9
Silicon Pow er SP001GBLTU133S01
A-data AD3U1333B2G9-B
Apacer 78.A1GC6.9L1
M2F2G64CB8HA4N-CG 0903.TW
M2Y2G64CB8HA9N-CG 0920.TW
Hynix HMT125U6AFP8C-H9N0 AA
FLFE85F-B8KG9 NEES
FLFE85F-B8KG9 NEUS
Kingston/KVR1333D3N9/2G
KVR1333D3N9/2G 9905403-011.A03LF
MT16JTF25664AY-1G4D1
MT8JTF12864AZ-1G4F1
PSC AL8F8G73D-DG1
Samsung M378B5673EH1-CH9
Silicon Pow er SP002GBLTU133S01
1 GB
KingMax FLGD45F-B8KG9 NEES
Elixir M2Y2G64CB8HA9N-DG 0928.TWr
KingMax FLGE85F-B8KG9 NEES
DDR3 1800 1 GB
Kingston KHX1800C9D3K3/3GX 9905402-046.A01LF
DDR3 2133 2 GB
Kingston KHX2133C9D3T 1K2/4GX
KingMax
Kingston
Mic ron
DDR3 1600
2 GB
2 GB
DDR3 1333
1
GB
KingMax
Samsung
Elixir
Table B: DDR3 (memory module) QVL (Qualified Vendor List)
The following DDR3 2100/1800/1600/1333/1066 memory modules have been tested
and qualified for use with this motherboard.

ECS A785GM-AD3 Specifications

General

Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	8
Power fan connector	Yes
Number of SATA connectors	5
PS/2 ports quantity	2
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	-
Audio chip	Realtek ALC888S
Certification	ROHS, EuP
Motherboard chipset	AMD 785G
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Vista, 7
PCI slots	3
Maximum graphics card memory	512 MB
RAID levels	0, 1
LAN controller	Realtek RTL8111DL
Networking features	Gigabit Ethernet
BIOS type	AMI
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	220 mm
Width	305 mm
