Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
Shutdown Temperature (CPU) Disabled
CPU Temperature : 53°C/127°F
NB Temperature : 55°C/131°F
System Temperature : 37°C/98°F
CPU FAN Speed : 4821 RPM
CPU Vcore : 1.328V
Vcc NB : 1.200V
VDIMM : 1.600V
VBAT : 3.216V
Case Open Warning Disabled
Chassis Opened No
Help Item
CMOS Setup Utility - Copyright (C) 1985-2005 , American Megatrends, Inc.
PC Health Status
f
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Default settings
F1:General Help
: Move
mnlk
Smart Fan Function
f
Scroll to this item and press <Enter> to view the following screen:
SMART FAN Control (Enabled)
This item allows you to enable/disable the control of the system fan speed by chang-
ing the fan voltage.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART FAN Control Enabled
Smart Fan Mode Normal
SMART Fan start PWM value 43
SMART Fan start TEMP.(°C) 27
DeltaT1 +3
SMART Fan Slope PWM value 3 PWM value/°C
CPU FAN Full Limit Temp 55°C
Disabled
Enabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Default settings
F1:General Help
: Move
mnlk
Options
