Introducing the Motherboard

• AMD 785G & AMD SB710

• AM3 socket for Phenom

II/Athlon

II/ Sempron

proces-

sors

• Supports “Hyper-Threading” technology CPU

• Dual-channel DDR3 1600 memory architecture

• 4 x 240-pin DDR3 DIMM sockets support up to 32 GB

• Supports DDR3 1600/1333/1066/800 DDR3 SDRAM

• 1 x PCI Express x16 slot

• 2 x PCI Express x1 slots

• 3 x PCI slots

• Supported by AMD SB710 Express Chipset

• 5 x Serial ATA 3.0 Gb/s Host Controllers

• Supports RAID 0, 1, and 10

• 2 x Ultra DMA133/100/66 devices

• 1 x eSATA 3.0 Gb/s device

• ALC888S 8-ch HD audio

• Realtek8111DL GigaLAN Controller (Colay RTL8103EL 10/

100 LAN Controller

• 1 x PS/2 keyboard & PS/2 mouse connector

• 6 x USB ports

• 1 x DVI port

• 1 x VGA port

• 1 x eSATA port

• 1 x RJ45 LAN connector

• 1 x Optical SPDIFO port

• 1 x Audio port (1x Line in, 4x Line out, 1x Optical SPDIF Out)

• 24-pin ATX Power Supply connector, 4-pin 12V connector

• 1 x CPU_FAN

• 1 x SYS_FAN

• 1 x NB_FAN

• 5 x SATA 3Gb/s connectors

• 3 x USB 2.0 headers support additional 6 USB ports

• 1 x Front panel header

• 1 x Chassis Intrusion Detect header

• 1 x Front panel audio header

• 1 x Speaker header

• 1 x CD in header

• 1 x Power on button

• 1 x Clear CMOS button • 1 x Power on LED (Green Light)

• 1 x Reset button • 1 x Stand by LED (Red Light)

Chipset

Memory

Expansion

Slots

Storage

Audio

LAN

Rear Panel I/O

Internal I/O

Connectors &

Headers

• AMI BIOS with 8Mb SPI ROM

• Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI

• Supports ACPI revision 3.0 specification

System BIOS

Form Factor • ATX Size, 305mm x 220mm

CPU

Specifications

• Support transfer rate up to 5200 mega-transfers per sec-

ond

Questions and Answers:

Need help?

Do you have a question about the ECS A785GM-AD3 and is the answer not in the manual?

ECS A785GM-AD3 Specifications

General

Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	8
Power fan connector	Yes
Number of SATA connectors	5
PS/2 ports quantity	2
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	-
Audio chip	Realtek ALC888S
Certification	ROHS, EuP
Motherboard chipset	AMD 785G
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Vista, 7
PCI slots	3
Maximum graphics card memory	512 MB
RAID levels	0, 1
LAN controller	Realtek RTL8111DL
Networking features	Gigabit Ethernet
BIOS type	AMI
BIOS memory size	64 Mbit
