38
Using BIOS
Smart Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be auto
adjusted depending on the CPU temperature. If you choose Quite mode, the fan speed
will be auto minimized for quiet environment. If you choose Silent mode, the fan
speed will be auto restricted to make system more quietly. If you choose Manual
mode, the fan speed will be adjust depending on users’ parameters.
Shutdown Temperature (CPU) (Disabled)
Enable you to set the maximum temperature the CPU can reach before powering
down
Press <Esc> to return to the main menu setting page.
Press <Esc> to return to the main menu setting page.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as CPU & System & NB temperature, CPU fan speed, CPU Vcore, ...etc.
• CPU Temperature
• NB Temperature
• System Temperature
• CPU FAN Speed
• CPU Vcore
• Vcc NB
• VDIMM
• VBAT
Case Open Warning (Disabled)
This item enables or disables the warning if the case is opened up, and the itembelow
indicates the current status of the case.
Chassis Opened (No)
This item indicates whether the case has been opened
SMART Fan start PWM value (43)
SMART Fan start TEMP. (°C) (27)
This item is used to set the start PWM value of the smart fan.
This item is used to set the start temperature of the smart fan.
DeltaT1 (+3)
This item specifies the range that controls CPU temperature and keeps it from going
so high or so low when smart fan works.
SMART Fan Slope PWM value (3 PWM value/°C)
This item is used to set the Slope Select PWM of the smart fan.
This item is used to set the limit temperature of the smart fan.
CPU FAN Full Limit Temp. (55°C)
