Setting Up eJIFFY
74
2. Then the “Save Image” window appears. You may rename the image file in the
“Name” column and save the file in a folder as the following picture shows.
1. Select the image you want to save and press the right key of your mouse to show
the menu, then click the option “ Save Image As” from the menu.
Q2: How to save image file through eWeb?
Select a root
directory.
Rename the image file.
Then select a
subdirectory
or click
“Create
Folder” to
create a new
folder.
Click here to
save the image
file.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ECS A785GM-AD3 and is the answer not in the manual?

ECS A785GM-AD3 Specifications

General IconGeneral
Number of memory slots4
Maximum internal memory8 GB
Processor socketSocket AM3
Processor manufacturerAMD
USB 2.0 connectors8
Power fan connectorYes
Number of SATA connectors5
PS/2 ports quantity2
USB 2.0 ports quantity6
Ethernet LAN (RJ-45) ports1
Firewire (IEEE 1394) ports-
Audio chipRealtek ALC888S
CertificationROHS, EuP
Motherboard chipsetAMD 785G
Audio output channels7.1 channels
Motherboard form factorATX
Compatible operating systemsWindows Vista, 7
PCI slots3
Maximum graphics card memory512 MB
RAID levels0, 1
LAN controllerRealtek RTL8111DL
Networking featuresGigabit Ethernet
BIOS typeAMI
BIOS memory size64 Mbit
Weight and Dimensions IconWeight and Dimensions
Depth220 mm
Width305 mm
