Chapter 3
A78F2P-M2 USER MANUAL
31
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Scroll to this item and press <Enter> to view the following screen:
Smart Fan Function
CPU Smart Fan/System Smart Fan/System Smart Fan2 Control (Enabled)
These items enable you to define the CPU smart fun/system smart fan/system smart
fan2 by smartly adjusting the CPU smart fan/system smart fan/system smart fan2.
When it is set at certain temperature, the CPU smart fan/system smart fan/system
smart fan2 PWM value will change accordingly.
Main Advanced Chipset M.I.B. III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Tct1 : +54
System Temperature : +27
O
C
CPU Fan Speed : 3296RPM
System Fan 1 Speed : N/A
System Fan 2 Speed : N/A
CPU Voltage : +1.656 V
DIMM Voltage : +1.564V
FCH Voltage : +1.298V
Smart Fan Function
PC Health Status
Main Advanced Chipset M.I.B. III Boot Security Exit
CPU Smart Fan Control Enabled
Smart Fan Mode Normal
High Limit Temperature 60
Low Limit Temperature 37
Hige Limit PWM 200
Low Limit PWM 88
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
System Smart Fan Control Enabled
Smart Fan Mode Normal
High Limit Temperature 60
Low Limit Temperature 37
Hige Limit PWM 200
Low Limit PWM 88
System Smart Fan2 Control Enabled
Smart Fan Mode Normal
High Limit Temperature 60
Low Limit Temperature 37
Hige Limit PWM 200
Low Limit PWM 88
