Core Clock multiplier (Auto)
This item is used to set Core clock multiplier.
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B. III (MB Intelligent BIOS III) Menu
Main Advanced Chipset M.I.B III Boot Security Exit
Core Clock multiplier
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit
Memory Clock (Auto)
This item is used to set Memory clock.
Memory Timing Configuration (Auto)
This item shows the information of Memory Timing.
Memory Clock is: (DDR3-1600/800Mhz)
This item shows current memory clock.
CAS# Latency (tCL) (9)
This item determines the operation of DDR SDRAM memory CAS(column address
strobe). It is recommanded that you leave this item at the default value. The 2T
setting requires faster memory that specifically supports this mode.
Command Rate (2T)
This item shows the information of Command Rate.
Core Clock multiplier Auto
Memory Clock Auto
Memory Clock is: (DDR3-1600/800Mhz)
(XMP Profile1 DDR3-2400 10-11-11-30) Ready
Memory Profiles2: None
Memory Profiles3: None
Memory Timing Configuration Auto
Load Memory Profile Disabled
Command Rate 2T
CAS# Latency(tCL) 9
RAS# to CAS# Delay (tRCD) 9
Row Precharge Time (tRP) 9
RAS# Active Time (tRAS) 26
Read CAS# Precharge (tRTP) 6
Row Cycle Time (tRC) 37
Write Recovery Time (tWR) 12
Active to Active Delay (tRRD) 5
Write to Read Delay (tWTR) 6
Four Active Window Delay (tFAW) 24
Row Refresh Cycle Time 0 (tRFC0) 4
Row Refresh Cycle Time 1 (tRFC1) 3
Row Refresh Cycle Time 2 (tRFC2) 4
Row Refresh Cycle Time 3 (tRFC3) 4
SB Spread Spectrum Enabled
XMP Profile 1 DDR3-2400 10-11-11-30 (Ready)
This item shows the state of XMP profile 1 DDR3-2400 10-11-11-30.
Memory Profiles2~3 (None)
These items show the information of performance memory profile2~3.
Load Memory Profile (Disabled)
This item enables or disables you to load memory profile.
