Using BIOS
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
M.I.B.III (MB Intelligent BIOS III)
Help Item
AMD Phenom (tm) II X4 900e Processor
Speed : 2400MHz, NB Clk: 2000MHz
Current CPU Frequency 2400MHz
Current CPU Voltage 1.1500v
Current NB Frequency 2000MHz
CPU Vcore : 1.200 V
VDIMM : 1.596 V
NB Voltage : 1.236 V
Memory Configuration Press Enter
CPU Frequency Ctrl: Auto
HT Frequency Auto
CPU/HT Reference Clock (MHz) 200
Auto Detect DIMM/PCI CIK Enabled
Spread Spectrum Enabled
CPU Voltage Disabled
DIMM Voltage Disabled
NB Voltage Disabled
HT Voltage 1.20v
f
M.I.B. III (MB Intelligent BIOS III)
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have in-
stalled in your system.
Memory Configuration
f
Scroll to this item and press <Enter> to view the following screen:
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Memory Configuration
mnlk: Move Enter : Select +/-/: Value F10: Save ECS: Exit
F1: General help F9: Optimized Defaults
Help Item
Options
Auto
Limit
Manual
Memory Configuration
Memory Clock Mode Auto
DRAM Timing Mode Auto
Bank Interleaving Auto
Channel Interleaving XOR of Address bits
Memory CLK : N/A, 667 MHz
CAS Latency (Tcl) : N/A, 9 Clk
RAS/CAS Delay (Trcd) : N/A, 9 Clk
Row Precharge Time (Trp) : N/A, 9 Clk
Min Active RAS (Tras) : N/A, 24 Clk
RAS/RAS Delay (Trrd) : N/A, 4 Clk
Row Cycle (Trc) : N/A, .33 Clk
Memory Clock Mode (Auto)
This item is used to set the memory clock mode.
DRAM Timing Mode (Auto)
This item enables you to specify the DRAM timing mode to be configured automati-
cally or manually.
Adjust HT Voltage
1.35V
1.3V
1.25V
1.2V
WARNING:
Doing overvoltage may re-
sult in damage to system.
To Next Page
