ECS A890GXM-A User Manual

43
Using BIOS
HT Voltage (Disabled)
This item allows user to adjust HT voltage when enabled.
AMD Phenom (tm) II X3 750e Processor Speed (2500MHz)
This is display-only field and displays the information of the CPU installed in your
computer.
NB Clk (2000MHz)
This item shows the frequency of Northbridge clock.
Current CPU Frequency (2500MHz)
This item shows the current CPU frequency.
Current CPU Voltage (1.1750v)
This item shows the current CPUvoltage.
Current NB Frequency (2000MHz)
This item shows the current NB frequency.
CPU Vcore (1.200V)
This item displays the current CPU voltage.
VDIMM (1.596V)
This item displays the current DIMM voltage.
Press <Esc> to return to the main menu setting page.
NB Voltage (1.5236V)
This item displays the current NB voltage.
