PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Scroll to this item and press <Enter> to view the following screen:
fSmart Fan Function
PC Health Status
Smart Fan Function
CPU Tct1 : +49
CPU Fan Speed : 2183 RPM
CPU Voltage : +1.416 V
DIMM Voltage : +1.528 V
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Main
Advanced Chipset M.I.B.III Boot Security Exit
ff
ff
f
Enter/Dbl Click : Select
+/- : Change Opt.
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
CPU Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
High Limit Temperature (
0
C) 60
Low Limit Temperature (
0
C) 37
High Limit PWM 200
Low Limit PWM 56
Main Advanced Chipset M.I.B.III Boot Security Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Enter/Dbl Click : Select
+/- : Change Opt.
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Smart Fan Control (Enabled)
This item enables you to define the CPU by smartly adjusting the CPU Fan. When it
is set at certain temperature, the CPU Fan PWM value will change accordingly.
Smart Fan Mode (Normal)
This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a
better operation environment. If you choose Normal mode, the fan speed will be
auto adjusted depending on the CPU temperature. If you choose Quiet mode, the
fan speed will be auto minimized for quiet environment. If you choose Silent mode,
the fan speed will be auto restricted to make system more quietly. If you choose
Manual mode, the fan speed will be adjust depending on users’ parameters.
To Next Page
