ECS A960M-M3 User Manual

Chapter 3
A960M-M3 USER MANUAL
44
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc.
Set Upstream Link Width
HT Control
Current Width Up: 16 bit
Upstream Link Width [Auto]
Current Width Down: 16 bit
Downstream Link Width [Auto]
Current IO HT Freq: 2200MHz
IO HT Frequency [Auto]
+/- : Change Opt.
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Enter/Dbl Click : Select
fHT Control
Scroll to this item and press <Enter> to view the following screen.
Current Width Up (16 bit)
This item shows the Current Width UP.
Upstream Link Width (Auto)
This item is used to set the Upstream Link Width.
Current Width Down (16 bit)
This item shows the Current Width Down.
Downstream Link Width (Auto)
This item is used to set the Downstream Link Width.
Current IO HT Freq: 2200MHz
This item shows the Current IO HT Frequency.
IO HT Frequency [Auto]
This item enables users to manually set up the HyperTransport frequency.
