5
A960M-M3 USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket
Socket AM3 for AMD FX
TM
/Phenom
TM
II /Athlon
TM
II/Sempron
TM
100 Series processors
2. CPU_FAN CPU cooling fan connector
3. DDR3_1~2 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. IDE Primary IDE connector
6. SYS_FAN System cooling fan connector
7. SPK Speaker header
8. SATA1~4 Serial ATA 3.0 Gb/s connectors
9. F_PANEL Front panel switch/LED header
10. F_USB1~2 Front panel USB 2.0 headers
11. USBPWR_F1 Front panel USB power select jumper
12. SPI_DEBUG SPI_debug header for factory use only
13. COM Onboard serial port header
14. LPT Onboard parallel port header
15. F_AUDIO Front panel audio header
16. PCI1~2 32-bit add-on card slots
17. CLR_CMOS Clear CMOS jumper
18. PCIEX1 PCI Express x1 slot
19. CASE Case open header
20. PCIEX16 PCI Express slot for graphics interface
21. ATX12V 4-pin +12V power connector
22. USBPWR_R1 Rear USB/PS2 power select jumper
