Step 4: Use the flow meter ball valve to relieve gas from nitrogen/air supply line to sprinkler system’s
AMD allowing the nitrogen generator to cycle on.
Step 5: Set nitrogen generator to bypass (air only mode) and fast fill sprinkler system with air to
3-5 psig (.2-.3 bar) below operating pressure.
Step 6: Change nitrogen generator to nitrogen mode, open the AMD inlet/outlet (regulated) valves,
close AMD fast fill (bypass) valve and complete filling of sprinkler system.
Step 7: When sprinkler system air pressure gauge reaches desired system operating pressure:
• Slowly decrease AMD regulator pressure (turn counter-clockwise) until pressure indicated
on HMI transitions from steady pressure to climbing pressure, the AMD regulator should
be properly set.
Step 8: Verify AMD operating with nitrogen generator using AMD Operation with nitrogen generator
verification procedure.
Step 9: Repeat Steps 4 thru 8 for each additional AMD connected to the nitrogen generator.
AMD Operation with Nitrogen Generator - Verification
Step 1: Systems not being checked - Close the all AMD valves.
Step 2: System being checked - Verify the AMD fast fill (bypass) valve is closed and the inlet/outlet
(regulated) valves are open.
Step 3: Set the cut-in (turn-on) pressure of the nitrogen generator to 3-5 psig (.2-.3 bar) below the
sprinkler system AMD set pressure. (See Maintenance Section for the Nitrogen Generator
Pressure Adjustment Procedure).
Step 4: Slowly drain 3-5 psi (.2-.3 bar) of pressure out of the sprinkler system.
Step 5: Use the flow meter ball valve to relieve gas from nitrogen/air supply line to sprinkler system
AMD’s allowing the nitrogen generator to turn on.
Step 6: Allow the sprinkler system to fill with nitrogen while monitoring the pressure on the HMI LCD
display in the nitrogen generator.
• As pressure increases in sprinkler system and on the HMI LCD display (through the AMD),
the pressure increase will be gradual.
• When the sprinkler system operating pressure reaches the AMD set pressure and the
AMD closes:
o The pressure on the sprinkler system air gauge will stop rising.
o The pressure on the pressure HMI LCD display will increase at a rapid pace until the
nitrogen generator turns off (cut-out) pressure.
Step 7: Compare the pressure indicated on the HMI LCD display at the transition (gradual increase to
rapid increase) with the pressure indicated on the system air pressure gauges.
NOTE: The pressure indicated on the HMI LCD display at the transition of gradual to rapid
increase will be the pressure at which the AMD pressure regulation device is currently
set.
• If the pressure indicated on the HMI LCD display at the transition (gradual increase to
rapid increase) is the sprinkler system’s target pressure, proceed to Step 9.
• If the pressure indicated on the sprinkler system’s air pressure gauge at the transition
(gradual increase to rapid increase) is LESS THAN the sprinkler system’s target pressure,
proceed to Step 8a.
• If the pressure indicated on the sprinkler system’s air pressure gauge at the transition
(gradual increase to rapid increase) is MORE THAN the sprinkler system’s target pressure,
proceed to Step 8b.
To Next Page
