ECS AdvancedIQ AG-675

33
ECS SMART Vent Assembly
In-Line Filter Assembly ECS SMART Vent Installation Schematic
½” Quick Connect
Connection To
Sprinkler System
Solenoid
Gas Sampling Port
In-Line Filter
HOUSING
Float Valve
Backpressure
Regulator
Restricted Venting
Orifice
Muffler
Y-Strainer
with Ball Valve
Isolation Ball Valve
Dry Pipe/Preaction
Sprinkler Valve
Filter Housing
Filter
Pressure Relief Valve
Wiring Harness
Installed in Conduit
Vent Assembly
Fire Sprinkler Riser
Control Box
Mounted to
Adjacent Wall
Nitrogen Supply
