Installing the Motherboard

SATA1~4: Serial ATA connectors

These connectors are used to support the new Serial ATA devices for the highest date

transfer rates (3.0 Gb/s), simpler disk drive cabling and easier PC assembly. It elimi-

nates limitations of the current Parallel ATA interface. But maintains register com-

patibility and software compatibility with Parallel ATA.

1 Ground 2 TX+

3 TX- 4 Ground

5 RX- 6 RX+

7 Ground - -

Pin Signal Name

TV_OUT1: TV-out header

Users may connect this header to your TV set to achieve the TV-out function.

SPDIFO: SPDIF out header

This is an optional header that provides an S/PDIF (Sony/Philips Digital Interface)

output to digital multimedia device through optical fiber or coxial connector.

1 SPDIF SPDIF digital output

2 VCC +5V power

3 Key No pin

4 GND Ground

Pin Signal Name

Function

WOL1: Wake On LAN connector (Optional)

If you have installed a LAN card, use the cable provided with the card to plug into the

WOL1 connector onboard. This enables the Wake On LAN (WOL) feature. When

your system is in a power-saving mode, any LAN signal automatically resumes the

system. You must enable this item using the Power Management page of the Setup

Utility in the BIOS. See Chapter 3 for more information.

1 5VSB +5V stand by power

2 GND Ground

3 Wake_up Wake up signal (low active)

Pin Signal Name Function

1 GND Ground

2 COMP Composite

3 LUM Luminance

4 GND Ground

5 CHROMA Chrominance

6 KEY No pin

ECS AMD690GM-M2 User Manual
