Using BIOS
Frequency/Voltage Control
This item enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
Shutdown Temperature (80°C/176°C)
This item enables or disables you to set the maximum temperature the system can
reach before powering down.
Warning Temperature (75°C/167°C)
This item allows users to manually set the warning temperature of the system.
System Component Characteristics
These fields provide you with information about the systems current operating status. You
cannot make changes to these fields.
• CPU Vcore
• VDIMM
• CPU Tcontrol
• System Temperature
• CPU Fan Speed
• System Fan Speed
Phoenix-Award WorkstationBIOS CMOS Setup Utility
Frequency/Voltage Control
NPT Fid control [Auto]
NPT Vid control [Auto]
AMD K8 Cool&Quit control [Auto]
DIMM Voltage Adjust [Normal]
SATA PHY Voltage [1.25V]
Auto Detect PCI Clk [Enabled]
Spread Spectrum [Disabled]
CPU Clock [200MHz]
Item Help
Menu Level
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Press <Esc> to return to the PC Health Status screen.
SMART Fan Control (Auto)
Press Ctrl + F1 to show this item. This item allows you to enable/disable the
control of the system fan speed by changing the fan voltage.
FAN1 START PWM VALUE (63)
Press Ctrl + F1 to show this item. This item displays the PWM value smart fan
starts.
FAN1 START Temp ° C (60)
Press Ctrl + F1 to show this item which specifies the temperature value smart
fan starts. When the CPU temperature is lower than the value, the fan will
function at start PWM value.
FAN1 Slope Select PWM/ ° C (2)
Press Ctrl + F1 to show this item. This item specifies the slope PWM value of smart
fan.
To Next Page
