Using BIOS
Press <Esc> to return to the Smart Fan Function page.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan
speed,...etc.
• CPU Temperature
• System Temperature
• CPU Fan Speed
• System Fan Speed
• CPU Vcore
• CPU VTT Voltage
• VDIMM
• PCH Voltage
Press <Esc> to return to the main menu setting page.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Smart Fan Function
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move

Options
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet
environment operation.
Silent: auto restricts
fan speed to make
system more quietly.
Manual: the fan adjust
depending on user’s
parameter.
CPU SMART FAN Control Enabled
SMART Fan Mode Manual
CPU SMART Fan start PWM 28
CPU SMART Fan start TEMP (°C)32
DeltaT +3
SMART Fan Slope PWM value 4 PWM value/°C
CPU FAN Full Limit Temp 57°C
SYS SMART FAN Control Disabled
Case Open Warning (Disabled)
This item enables or disables the warning if the case is opened up, and the item below
indicates the current status of the case.
Chassis Opened (No)
This item indicates whether the case has been opened.

ECS H55H-I Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	-
Compatible processor series	Intel Core i3, Intel Core i5
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	6
Audio chip	Realtek ALC892
Power source type	ATX
Audio output channels	- channels
Motherboard form factor	mini ITX
On-board graphics card	No
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111D(L)
Networking features	Gigabit Ethernet
BIOS type	AMI
BIOS memory size	64 Mbit

Weight and Dimensions

Width	170 mm
