ECS H55H-I User Manual

41
Using BIOS
PCIE Over-clocking Func (Disabled)
This item enables or disables the PCIE over-clocking function.
Spread Spectrum (Enabled)
If you enable spread spectrum, it can significantly reduce the EMI (Electro-Magnetic
Interference) generated by the system.
Voltage Function (Disabled)
Use this item to enable or disable the
Voltage Function. If enable, users can increasethe
hardware voltage through BIOS settings.
Intel (R) Core (TM) i5 CPU 661 @ 3.33GHz
This is display-only field and displays the information of the CPU installed in your
computer.
Auto Detect DIMM/PCI Clk (Enabled)
When this item is enabled, BIOS will disable the clock signal of free DIMM/PCI slots.
Ratio Status/Ratio Actual Value (Unlocked/25)
These items show the locked/unlocked ratio status and the actual ratio of the CPU
installed in your system.
Current Memory Frequency (1333MHz)
This item displays the current memory frequency.
CPU Vcore (1.164 V)
This item displays the current CPU voltage.
Memory Current Type (9-24-9-9-10-74-5-4-5-20)
This item displays the current memory type.
VDIMM (1.500 V)
This item displays the current DIMM voltage.
VAXG (1.368 V)
This item displays the current PCH voltage.
Press <Esc> to return to the main menu setting page.

ECS H55H-I Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333 MHz
Processor socket	-
Compatible processor series	Intel Core i3, Intel Core i5
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	6
Audio chip	Realtek ALC892
Power source type	ATX
Audio output channels	- channels
Motherboard form factor	mini ITX
On-board graphics card	No
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111D(L)
Networking features	Gigabit Ethernet
BIOS type	AMI
BIOS memory size	64 Mbit

Weight and Dimensions

Width	170 mm
