H61H2-I5 USER MANUAL

Chapter 2

Press <Esc> to return to the chipset menu page.

Main Advanced Chipset M.I.B III Boot Security Exit

PCH Configuration

Restore AC Power Loss [Power Off]

Audio Configuration

Azalia HD Audio [Enabled]

Case Open Warning [Disabled]

Chassis Opened [No]

Select AC power state when power

is re-applied after a power failure.

F2:Previous Values

F1:General Help

+/- : Change Opt.

Enter : Select

:Select Screen

:Select Item

F3:Optimized Defaults

F4:Save & Exit

ESC:Exit

Restore AC Power Loss (Power Off)

This item enables your computer to automatically restart or return to its operating

status.

Audio Configuration

This item shows the information of the audio configuration.

Azalia HD Audio (Enabled)

This item enables or disables Azalia HD audio.

Case Open Warning (Disabled)

This item enables or disables the warning if the case is opened up, and the item

below indicates the current status of the case.

Chassis Opened (No)

This item indicates whether the case has been opened.

fPCH Configuration

Scroll to this item and press <Enter> to view the following screen:

Questions and Answers:

Need help?

Do you have a question about the ECS H61H2-MV and is the answer not in the manual?

ECS H61H2-MV Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Serial port headers	1
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA II
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111E
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Audio chip	Realtek ALC662
Certification	CE/FCC, ErP/EuP, WHCK
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 8, Windows 8 x64, Windows XP Home, Windows XP Home x64
DirectX version	11
Parallel processing technology support	Not supported
BIOS type	AMI
BIOS memory size	64 Mbit
Trial software	Muzee
Bundled software	eBLU, eDLU, eSF\\r Norton Internet Security, CyberLink PowerDVD, CyberLink PowerDirector 9
