H61H2-I5 USER MANUAL

Chapter 1

Table of Motherboard Components

LABEL COMPONENTS

1. CPU Socket LGA1155 socket for Intel® Sandy/Ivy Bridge Processors

2. PCIEX16 PCI Express slot for graphics interface

3. F_AUDIO Front panel audio header

4. USBPWR_R Rear USB/PS2 power select jumper

5. CPU_FAN 4-pin CPU cooling fan connector

6. SYS_FAN 3-pin system cooling fan connector

7. ATX12V1 4-pin +12V power connector

8. VGA_HEADER VGA header (Optional)

9. F_PANEL Front panel switch/LED header

10. SATA1~4 Serial ATA 3.0 Gb/s connectors

11. SPK Speaker header

12. CASE Case open header

13. CLR_CMOS Clear CMOS jumper

14. F_USB2 Front panel USB 2.0 header

15. USBPWR_F Front Panel USB power select jumper

16. F_USB1 Front panel USB 2.0 header

17. COM Onboard serial port header

18. ATX_POWER Standard 24-pin ATX power connector

19. DDR3_1~2 240-pin DDR3 Module slots

20. ME_UNCLOCK ME Unlock header-for factory use only

Questions and Answers:

Need help?

Do you have a question about the ECS H61H2-MV and is the answer not in the manual?

ECS H61H2-MV Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Serial port headers	1
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA II
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111E
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Audio chip	Realtek ALC662
Certification	CE/FCC, ErP/EuP, WHCK
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 8, Windows 8 x64, Windows XP Home, Windows XP Home x64
DirectX version	11
Parallel processing technology support	Not supported
BIOS type	AMI
BIOS memory size	64 Mbit
Trial software	Muzee
Bundled software	eBLU, eDLU, eSF\\r Norton Internet Security, CyberLink PowerDVD, CyberLink PowerDirector 9
