ECS H77H2-M3 User Manual

Chapter 3
H77H2-M4 USER MANUAL
51
IA Core Current Max (1/8 Amp) (780)
Use this item to control CPU Current Limit.
iGFX Core Current Max (1/8 Amp) (260)
Use this item to control iGFX Core Current Limit.
Enhanced Intel SpeedStep Technology (Enabled)
This item allows users to enable or disable the EIST (Enhanced Intel SpeedStep Tech-
nology).
Turbo Mode (Enabled)
This item allows you to control the Intel Turbo Boost Technology.
Runtime Turbo Enable (Disabled)
This item shows if CPU support Runtime Turbo.
Long Duration Maintained (28)
Use this item to control the time window over PL1 Value should be maintained. This
is for Turbo Mode.
Short Duration Power Limit Override (950)
Intel(R) Turbo Boost Technology will use this power limit for a very short duration.
After that, the Long Duration Power Limit will be honored.
1/2/3/4 Core Ratio Limit (39/38/37/36)
This item shows the Core Ratio Limit Value.
Over Clocking Extra Vol. (1/256 V) (0)
This item allows you to control Extra CPU Voltage.
Long Duration Power Limit Override (760)
Intel(R) Turbo Boost Technology will use this power limit during the Long Duration
Power Limit Time Window.
Press <Esc> to return to the M.I.B III Menu page.
