Chapter 3
H77H2-M4 USER MANUAL
54
Warning:
Over-clocking components can adversely affect the reliability of the system
and introduce errors into your system. Over-clocking can permanently
damage the motherboard by generating excess heat in components that are
run beyond the rated limits.
B.O.M.P Technology (Enabled)
This item allows users to enable or disable B.O.M.P technology. This function can
run safe setting to setup menu when system boot fail 3 times.
CPU/VTT/DIMM Voltage (Auto)
These items allows you to adjust the CPU/VTT/DIMM voltage.
Genuine Intel(R) CPU @ 2.20GHz (2200 MHz)
This item shows the CPU information.
Processor Speed (2200 MHz)
This item shows the CPU speed.
Memory Frequency (1333 MHz)
This item shows the memory frequency.
Total Memory (2048 MB (DDR3))
This item shows the total memory.
CPU Current Voltage (0.888V)
This item shows the CPU current voltage.
VTT Current Voltage (1.044V)
This item shows the VTT current voltage.
DIMM Current Voltage (1.536V)
This item shows the DIMM current voltage.
When end-users encounter failure after attempting over-clocking, please take the
following steps to recover from it.
1. Shut down the computer.
2. Press and hold the “Page Up Key (PgUp)” of the keyboard, and then boot the PC
up.
3. Two seconds after the PC boots up, release the “Page Up Key (PgUp)”.
4. The BIOS returns to the default setting by itself.
Fail-Safe Procedures for Over-clocking
