ECS H81H3-M3 User Manual

H81H3-M3 USER MANUAL
52
Chapter 3
Press <Esc> to return to the M.I.B. III Menu page.
Memory Configuration
Scroll to this item to view the following screen:
Memory RC Version (1.4.0.3)
Memory Frequency (1067 Mhz)
This item shows the memory frequency.
Total Memory 2048 MB (DDR3)
This item shows the total memory.
Memory Profiles (Automatic)
This item allows you to select the memory mode: Automatic, Manual, XMP Profile 1
or 2.
F4: Save & Exit
Main Advanced Chipset M.I.B. III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
The selection of Memory
Profiles which impacts
memory sizing behavior.
This item shows the Memory RC Version.
Memory Information
Memory RC Version 1.4.0.3
Memory Frequency 1067 Mhz
Total Memory 2048 MB (DDR3)
Memory Profiles Automatic
Memory Frequency 1067
Tming Default Current Target
tCL 7 7 7
tRCD 7 7 7
tRP 7 7 7
tRAS 20 20 20
NMode 1 1 Auto
tWR 8 8 8
tRFC 59 59 59
tRRD 4 4 4
tWTR 4 4 4
tRTP 4 4 4
tCWL 6 6 6
tREFI 4160 4160 4160
tFAW 20 20 20
