LABEL COMPONENTS
1. CPU Socket LGA1150 socket
2. CPU_FAN 4-pin CPU cooling fan connector
3. DDR3_1~2 240-pin DDR3 Module slots
4. FDD Floppy disk header (optional)
5. ATX_POWER Standard 24-pin ATX power connector
6. TPM Trusted Platform Module header (optional)
7. USB3F Front panel USB 3.0 header (optional)
8. USBPWR_F2 Front panel USB power select jumper
9. SATA2_3~4 Serial ATA 3.0 Gb/s connectors
10. SATA3_1~2 Serial ATA 6.0 Gb/s connectors
11. CLR_CMOS Clear CMOS jumper
12. F_PANEL Front panel switch/LED header
13. CASE CASE open header
14. ME_UNLOCK ME unlock header-for factory use only
15. F_USB1~2 Front panel USB 2.0 headers
16. USBPWR_F1 Front panel USB power select jumper
17. COM1~2 Onboard serial port headers
18. LPT Printer Header
19. PCI 32-bit add-on card slot
20. F_AUDIO Front panel audio header
21. PCIE1~2 PCI Express x1 slots
22. PCIEX16 PCI Express slot for graphics interface
23. SYS_FAN 4-pin system cooling fan connector (co-lay 3-pin)
24. USBPWR_R2 Rear USB3 power select jumper
25. USBPWR_R1 Rear USB/PS2/LAN power select jumper
26. ATX12V 4-pin +12V power connector
