ECS H81H3-M7 User Manual

Chapter 3
B85H3-M7 USER MANUAL
55
ChReadVref 0.744 V (Auto)
This item allows you to adjust the ChReadVref from 0 to 108, and the default is 54,
1 step is 4mV.
Over Voltage Configuration
Scroll to this item to view the following screen:
Main Advanced Chipset M.I.B. III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Ch0WriteVref 0.744 V (Auto)
This item allows you to adjust the Ch0WriteVref from 0 to 108, and the default is 54,
1 step is 4mV.
Ch1WriteVref 0.744 V (Auto)
This item allows you to adjust the Ch1WriteVref from 0 to 108, and the default is 54,
1 step is 4mV.
ChVrefCA 0.744 V (Auto)
This item allows you to adjust the ChVrefCA from 0 to 108, and the default is 54, 1
step is 4mV.
Ch0WriteVref 0.744V Auto
Ch1WriteVref 0.744 V
Auto
ChVrefCA 0.744V Auto
ChReadVref 0.744V
CPU Adaptive Voltage Target(mV)
CPU Voltage Mode
CPU Voltage Offset(mV)
Offset Preflx
RING/Cache Adaptive Voltage Target(mV) 0
RING/Cache Voltage Mode
RING/Cache Voltage Offset(mV)
Offset Prefix
SVID Control Enable Enabled
SVID Override Voltage Target(mV) 0
FIVR Faults Enable Enabled
FIVR Efficiency Enable Enabled
GT Adaptive Voltage Target(mV) 0
GT Voltage Mode Adaptive
GT Voltage Offset (mV) 0
Offset Prefix +
UNCORE Voltage Offset (mV) 0
Offset Prefix +
IOA Voltage Offset (mV) 0
Offset Prefix +
Auto
Adaptive
Adaptive
0
+
+
0
