7
H87H3-M4
USER MANUAL
Chapter 1
A: Center & Woofer D: Line-in
B: Back Surround E: Front Out
C: Side Surround F: Mic_in Rear
The above port definition can be changed to audio input or audio output by changing the
driver utility setting.
8. Audio ports
Use the audio jacks to connect audio devices. The D port is for stereo line-in
signal,while the F port is for microphone in signal. This motherboard supports 8-
channel audio devices that correspond to the A, B, C, and E port respectively. In
addition, all of the 3 ports, B, C, and E provide users with both right & left channels
individually.Users please refer to the following note for specific port function
definition.
To Next Page
