Chapter 3
H87H3-M4 USER MANUAL
69
Over Voltage Configuration
Scroll to this item to view the following screen:
Main Advanced Chipset M.I.B. III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Processor Input Voltage 1.752 V Auto
DIMM Voltage 1.512 V Auto
Ch0WriteVref 0.760 V Auto
Ch1WriteVref 0.756 V Auto
ChVrefCA 0.756 V Auto
ChReadVref 0.756 V Auto
CPU Adaptive Voltage Target(mV) 0
CPU Voltage Mode Adaptive
CPU Voltage Offset(mV) 0
Offset Preflx +
RING/Cache Adaptive Voltage Target(mV) 0
RING/Cache Voltage Mode Adaptive
RING/Cache Voltage Offset(mV) 0
Offset Prefix +
SVID Control Enable Enabled
SVID Override Voltage Target(mV) 0
FIVR Faults Enable Enabled
FIVR Efficiency Enable Enabled
GT Adaptive Voltage Target(mV) 0
GT Voltage Mode Adaptive
GT Voltage Offset (mV) 0
Offset Prefix +
UNCORE Voltage Offset (mV) 0
Offset Prefix +
IOA Voltage Offset (mV) 0
Offset Prefix +
IOD Voltage Offset (mV) 0
Offset Prefix +
DIMM Voltage 1.512 V (Auto)
This item allows you to adjust the DIMM voltage.
Processor Input Voltage 1.752 V (Auto)
This item allows you to adjust the processor input voltage.
ChVrefCA 0.756 V (Auto)
This item allows you to adjust the ChVrefCA from 0 to 108, and the default is 54, 1
step is 4mV.
Ch0WriteVref 0.760 V (Auto)
This item allows you to adjust the Ch0WriteVref from 0 to 108, and the default is 54,
1 step is 4mV.
Ch1WriteVref 0.756 V (Auto)
This item allows you to adjust the Ch1WriteVref from 0 to 108, and the default is 54,
1 step is 4mV.
