5
Table of Motherboard Components
Label Component
AGP Accelerated Graphics Port (supports 1.5V AGP card only)
ATX1 Standard 20-pin ATX power connector
ATX2 ATX 12V Power Connector
AUDIO1 Front audio connector
CASFAN1 Case fan connector
CDIN1 Primary CD-in connector
CPU SOCKET Socket A for AMD CPU
CPUFAN1 Cooling fan for CPU
DIMM1~ DIMM3 Three 184-pin DDR SDRAM
FDD1 Floppy disk drive connector
IDE 1 Primary IDE channel
IDE 2 Secondary IDE channel
JP1 Clear CMOS jumper
PANEL1 Connector for case front panel switches and LED indicators
PCI1 ~ PCI5 Five 32-bit add-on card slots
PANEL1 Panel connector for case switches and LEDs
PWRFAN1 Power fan connector
SPDIFO1 SPDIF out header (optional)
SPEAKER1 Speaker connector
USB3 Connector for front panel USB ports
USBCR1 USB Card reader connector
This concludes Chapter 1. The next chapter explains how to install the moth-
erboard.
