ECS NFORCE6M-A2 User Manual

5
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1.CPU Socket
Socket AM3 Phenom
TM
II/Athlon
TM
II processor
2.DDR3_1~4 240-pin DDR3 SDRAM slots
3.ATX_POWER Standard 24-pin ATX power connector
4.IDE Primary IDE connector
5.SATA1~4 Serial ATA connectors
6.SYS_FAN System cooling fan connector
7.SPK Speaker header
8.CLR_CMOS Clear CMOS jumper
9.USBPWR_F Front USB power select jumper
10.F_PANEL Front panel switch/LED header
11.F_USB1~3 Front Panel USB headers
12.FDD Floppy disk drive connector
13.SPDIFO SPDIF out header
14.CD_IN Analog audio input connector
15.F_AUDIO Front panel audio header
16.PCI1~3 32-bit add-on card slots
17.PCIE PCI Express x1 slot
18.PCIEX16 PCI Express x16 slot for graphics interface
19.CPU_FAN CPU cooling fan connector
20.ATX12V Standard 4-Pin ATX power connector
21.USBPWR_R Rear USB power select jumper
