ECS P55H-A2 User Manual

40
Using BIOS
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Function Enabled
Smart Fan Mode Silent
CPU SMART Fan start PWM 5
SMART Fan start PWM TEMP(-) 26
DeltaT +3
SMART Fan Slope PWM value 6
CPU Fan Full Speed Offset(-) 6
SYS SMART FAN Control Disabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Load Default Settings
F1:General Help
: Move
mnlk
Options
Press <Esc> to return to the Smart Fan Function page.
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet en-
vironment operation.
Silent: auto restricts fan
speed to make system
more quietly.
Manual: the fan adjust
depending on user’s
parameter.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Function Enabled
Smart Fan Mode Manual
CPU SMART Fan start PWM 5
SMART Fan start TEMP. (-) 26
DeltaT +3
SMART Fan Slope PWM value 6
CPU Fan Full Speed Offset(-) 6
SYS SMART FAN Control Disabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Load Default Settings
F1:General Help
: Move
mnlk
Options
Press <Esc> to return to the PC Health Status page.
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet en-
vironment operation.
Silent: auto restricts fan
speed to make system
more quietly.
Manual: the fan adjust
depending on user’s
parameter.
