Using BIOS
ECS supports the latest PECI host technology. While using Lynnfield CPU,
the original images of the BIOS item “PC Health Status” and “Smart FAN
Function” will be replaced by PECI mode and negative number. (The max
data from PECI is zero.)
Help Item
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
PC Health Status
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Press <Esc> to return to the PC Health Status page.
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Control Enabled
SMART Fan start PWM value 28
SMART Fan start Offset (-) 30
CPU DeltaT +3
Fan1 Slope PWM value/1 Unit 5
Fan1 Full Speed Offset (-) 10
SMART Fan2 Control Disabled
Disabled
Enabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Options
-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
System Temperature 35°C/95°F
CPU Fan Speed: 2156 RPM
System Fan Speed: N/A
CPU Vcore: 1.072V
VDIMM: 1.504V
-=- PECI Mode-=-
Offset to TCC Activation Temp.: -19
