ECS X58B-A2 - PC Health Status Monitoring

37
Using BIOS
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
CPU SMART Fan Control Disabled
Smart Fan Function
f
Scroll to this item and press <Enter> to view the following screen:
Disabled
Enabled
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
SYSTEM SMART Fan Control Disabled
Options
PC Health Status
This item lets you monitor the parameters for critical voltages, temperatures and fan
speeds.
-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
System Temperature : 34°C/93°F
CPU Fan Speed : 2045 RPM
System Fan Speed : 0 RPM
CPU Vcore : 1.200 V
CPU VTT : 1.232 V
VDIMM : 1.472 V
NB Vcore : 1.120 V
SB VCC : 1.456 V
SB Vcore : 1.232 V
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -55
Help Item
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
PC Health Status
f
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
CPU/SYSTEM SMART Fan Control (Disabled)
These items are used to enable or disable the CPU/System fan speed control function.
If enabled, the CPU/System fan runs at different speed according to the CPU/
System temperature. You can adjust the fan speed with EasyTune based on system
requirements. If disabled, CPU/System fan runs at full speed. (Default: Enabled)
Press <Esc> to return to the PC Health Status page.
