ECTIVE DSC 25 User Manual

For battery MAIN I, set the correct charging program for the battery
type (lead or lithium-iron phosphate technology).
Prior to start-up, set the correct characteristic line of charging suitable
for the battery to avoid damage to the battery! Only use lithium
iron-phosphate batteries in execution with integrated BMS (battery
management system) and safety circuit!
Set the DIP switches on the side of your device to the correct battery
type in accordance with the following tables:
*These values apply to 12 V or 24 V systems
1 2 3 4
GEL
↓ ↑ ↓ ↓
Wet
↓ ↓ ↑ ↓
AGM
↓ ↓ ↓ ↑
LiFePO4
↑ ↓ ↑ ↑
1 2
GEL
↓ ↓
Wet
↑ ↓
AGM
↓ ↑
LiFePO4
↑ ↑
DSC 12, DSC 25 SC 20, SC 40
Instructions for Battery Charging
(Pleaseconsulttheconnectionplanforyourdevice!)
Battery
Type
Voltage
(Boost Charging)
Voltage
(Float Charging)
Standard
Temperature
DSC12,
DSC25
SC20,
SC40
DSC12,
DSC25
SC20,
SC40
DSC12,
DSC25
SC20,
SC40
GEL
14,3V
(3-10h)
14,3V/
28,6V*
13,8V
13,8V/
27,6V*
20°C 25°C
Wet
14,4V
(1,5-6h)
14,7V/
29,4V*
13,45V
13,5V/
27V*
20°C 25°C
AGM
14,7V
(1,5-5h)
14,4V/
28,8V*
13,5V
13,5V/
27V*
20°C 25°C
LiFePO4
14,6V
(0,5-3h)
14,6V/
29,2V*
13,6V
13,6V/
27,2V*
20°C 25°C
Setting the Battery Charging Program
Charging Parameters
32
