SD5/SD6 Ultrasonic TableTop Doppler User Manual Introduction
- 8 -
2.2 Probes
WARNING
Do not touch the charge sockets of the Doppler probe and the patient simultaneously.
CAUTION
1. Do not immerse the probe (and the probe cable) in any liquid.
2. Do not stretch the probe cable for more than three meters.
Wireless Probe:
Wired Probe:
Figure 2-6 Top View of the Probe
Figure 2-7 Probe Control Keys
Figure 2-8 Bottom View of the Probe
1 Acoustic Face
2 Probe Control Keys
3 Probe Socket
4 Probe Cable
2
1
5 6 7 8
9 Probe Type Label
10 Probe Battery Compartment
11 Probe Charge Socket
9 10 11
4
3
1
2
5 Volume Decreasing Key
6 Volume Increasing Key
7 Power Key (only available
on wireless probe)
8 Probe Indicator
