SD5/SD6 Ultrasonic TableTop Doppler User Manual Introduction
- 7 -
WARNING
Please do not touch the probe sensor socket and the patient simultaneously.
Figure 2-3 Main Unit Control Keys
Figure 2-4 Back View of the Main Unit
Figure 2-5 Right View of the Main Unit
NOTE:
The main unit is not waterproof. Do not immerse it in any type of liquid.
18
17
16
20
19
16 Fuses
17 Power Socket
18 Equipotential Grounding
Terminal
19 Main Unit Label
20 Earphone Socket
21 Battery Compartment
21
11 12 13 14 15
11 Main Unit Indicator
12 On/OFF Key
13 Setup Key / Confirm Key
14 Up Key /
Record/Play Control Key
15 Down Key /
Print Control Key
