Operating Controls
Please Note:
Controls shown are for the model indicated.
The location of these controls may vary on the
different models.
Due to improvements and changes in the
equipment, the illustration shown may be vary
from the actual machine.
Figure 4
Gasoline Powered
(2-GC)
Dust Skirt
Vacuum port
Engine Stop Switch
Cushioned
hand grips
Choke Control
Throttle
Recoil
Starter Grip
Figure 3
Electric Powered
(2-EC)
Electric Motor
Power
On/Off
Switch
Electrical
Plug
Vibration
Dampening
Handles
Dust Skirt
Water Hook-up
and on/off valve
Vacuum port
Figure 2
Electric Powered
(S-EC)
Electric Motor
Power
On/Off
Switch
Electrical
Plug
Vibration
Dampening
Handles
Dust Skirt
Water Hook-up
and on/off valve
back of machine
Vacuum port
Figure 5
Gasoline Powered
(411)
Throttle
Depth
Control
Vibration
Dampening
Handles
Dust Skirt
Water Hook-up
and on/off valve
Vacuum port
Recoil
Starter Grip
Choke Control
NOTE: Operating controls are the same for the gasoline
and propane models.
NOTE: Operating controls are the same for the gasoline
and propane models.
Water Hook-up
and on/off valve
