Changing To Left-Side Cutting:
• Disconnect water hose from the blade guard.
• Using SAE 9/16” and 3/4” wrenches, remove the bolts on the blade guard.
• On the other side of the machine, remove the arbor shaft guard.
• You will have to re-route the water hose to the other side of the engine. It may be necessary to pull the hose back
through the hole in the main body of the machine and allow it to run directly up the left side. Be sure that the hose
will not interfere with or get caught on any moving parts.
• Reattach both guards.
• Reattach hose to the blade guard.
Blade Guard
Left Side Arbor Shaft Guard
Possible Diamond Blade Problems
