EDGE-1830 / EDGE-2440 / EDGE-3240 / EDGE-2460 / EDGE-3260 / EDGE-3860 / EDGE-4460 / EDGE-3270
Installation and Operating Manual
Original Instruction Manual 17 Rev 1.0, July 2019
FINAL CONNECTIONS
Final installation and connection of gas and electrical should be performed by a licensed plumber and
electrician. Gas pressures, (inlet and the high/low fire) of this oven will need to be checked and set
to specifications listed in this manual. Electrical supply to this oven must be inspected and meet the
specifications listed in this manual.
The electrical supply is to be directly connected within the side mounted electrical box. Remove the
3 lid screws to access these connection points. Ensure the earth ground is properly terminated to the
marked bonding point.
WARNING
Always check for leaks after making any gas supply piping connections or performing any
service on the oven.
WARNING
To prevent damage to the oven and personal injury or death, the voltage, phase and grounding
of the electrical supply must be inspected and verified prior to energizing.
RESTRAINT CABLE
IMPORTANT
OVENS EQUIPPED WITH CASTERS:
(1) Adequate means must be provided to limit movement of the appliance without depending
on the connector, quick-disconnect device, or associated piping to limit appliance
movement.
(2) The restraining device must be attached to the mounting eye located on the left side of
the oven base assembly.
All EDGE ovens are equipped with casters, and a restraint cable must be installed to limit movement
of the oven without straining the gas or electrical connections. One end of the restraint cable is
anchored to the wall, and the other end is anchored to the mounting eye located on the left side of the
oven base assembly.
Ensure that the restraint cable limits movement of the oven so that no strain is placed on either the
gas supply quick-disconnect fitting or the electrical power cord.
After connecting the restraint cable, move the oven into its final position and lock the casters.
Whenever any maintenance or service is performed and the restraint must be disconnected, ensure
that it is reconnected as soon as the oven is returned to its normal installed position.
