EDGE-1830 / EDGE-2440 / EDGE-3240 / EDGE-2460 / EDGE-3260 / EDGE-3860 / EDGE-4460 / EDGE-3270
Installation and Operating Manual
Original Instruction Manual 29 Rev 1.0, July 2019
OVEN OPERATION
Menu System Overview
Additional operation features are found in the Menu System. To access this menu, touch and swipe
the display screen, Left or Right.
The menu icons are: Information, Settings, Power
- Information: The information menu is useful for viewing Alarm history, Software version,
Serial number, Build date, System voltage, Belt demand, iHeat information and for Exporting
Logged data files.
- Settings: The CUSTOMER level Settings Menu provides access to Units of Measurement,
Customer PIN setup, Belt Direction, Software Updating, and Recipe Download/Upload. This
menu is protected by the Customer PIN.
- Power: Touching the Power icon will simply place the oven into Cool Down mode, following
a few seconds of delay. The oven fans will continue to run until the oven temperature falls
below 225F or 107C. Normal operation can be resumed by touching and holding the Power
icon on the cooldown screen.
Basic Operation
Control Use and Cleaning: The EDGE G2 display is a “touch” screen. Do not strike or impact the
screen with hard objects. Clean with a lightly dampened cloth, do not directly spray the display with
cleaning solutions or water.
Power Up: Power up and starting the oven system is performed by turning the POWER switch to the
ON position. Allow 5 seconds for the system to power up. Touch the power icon on the display.
