No. Description H-Freq. (KHz) V-Freq. (Hz)
1 VESA 640×400 31.480 60
2 VESA 640×480 31.649 70
3 VESA 640×480 37.862 72
4 VESA 640×480 37.500 75
5 VESA 800×600 60
6 VESA 800×600 70
7 VESA 800×600 48.077 72
8 VESA 800×600 46.875 75
9 VESA 1024×768 48.363 60
10 VESA 1024×768 56.476 70
11 VESA 1024×768 56.476 72
12 VESA 1024×768 60.023 75
13 VESA 1152×864 54.948 60
14 VESA 1152×864 66.095 70
15 VESA 1152×864 60.000 72
16 VESA 1152×864 66.095 75
17 VESA 1280×768 60.000 60
18 VESA 1280×768 60.000 70
19 VESA 1280×768 60.000 75
20 VESA 1280×800 75.000 60
21 VESA 1280×800 75.000 70
22 VESA 1280×800 75.000 75
23 VESA 1280×1024 63.981 60
24 VESA 1280×1024 79.977 70
25 VESA 1280×1024 63.981 72
26 VESA 1280×1024 79.977 75
27 VESA 1360×768 79.977 60
28 VESA 1440×900 79.977 60
29 VESA 1400×1050 79.977 60
30 VESA 1600×1200 79.977 60
31 VESA 1680×1050 79.977 60
32 VESA 1920×1200 79.977 60
Display Mode Support
19” Series Support 01~28 Mode
22” Series Support 01~31 Mode
24” Series Su
pp
ort 01~32 Mode
