EdgeStar AP12000S-1 Service Manual

10
NO.
PART NAME
NO.
PART NAME
1
BASE PLATE
34
MAIN PCB
2
CASTOR
35
PCB COVER
3
DRAIN TANK COVER
36
PLATE
4
FLOAT BRACKET
37
EVAPORATOR
5
FLOAT
38
FAN HOUSING
6
FLOAT SWITCH
39
FAN HOUSING
7
FAN MOTOR
40
FAN MOTOR
8
INDOOR AMBIENT SENSOR
41
BEARING
9
BRACKET
42
CROSS FLOW FAN
10
COMPRESSOR
43
SCREEN
11
RUBBER FOOT
44
AIR DEFLECTOR-A
12
CONDENSER
45
AIR DEFLEETOR-B
13
Y TUBE
46
BAR
14
CONNECTOR PIPE
47
CONTROL PANEL PCB
15
DISCHARGE PIPE
48
CONTROL PLATE
16
SUCTION PIPE
49
CONTROL PANEL
17
CONNECTOR PIPE
50
FRONT PANEL
18
CONNECTOR PIPE
51
POWER SUPPLY CORD
19
4-WAY REVERSING VALVE
52
SOFT CAP
20
BRACKET
53
PLUG
21
PLUG
54
REAR PANEL
22
CAPILARY TUBE
55
AIR FILTER
23
FAN MOTOR
56
BRACKET
24
FAN HOUSING
57
SENSOR
25
BLOWER WHEEL
58
REMOTE CONTROL
