EdgeStar AP12000S-1 - Exhaust Hose and Draining Information; Notes Regarding the Exhaust Hose; Direct Drainage Procedure

11
NO.
PART NAME
NO.
PART NAME
26
FAN HOUSING
59
HEAT EXHAUST HOSE
27
BRACKET
60
DUCT CONNECTOR
28
CAPACITOR FOR FAN MOTOR
61
GRATED ADAPTOR
29
STRIKE
62
EXHAUST CAP
30
CAPACITOR FOR COMPRESSOR
63
WINDOW PLATE W/ HOLE
31
CAPACITOR FOR FAN MOTOR
64
WINDOW PLATE
32
TERMINAL BLOCK
65
SMALL SCREW
33
BRACKET
66
LARGE SCREW
