EdgeStar AP310SS Manual

Fig. 5:
Correct terminal
Loose clip
8) Once the loose clip/wire is reconnected, reassemble the unit- first close up the
back of the machine and rescrew the last 6 screws.
9) To properly reinstall the cap for the unit, slide the back
of the cap fully onto the
air conditioner. Then, apply pressure downward on the front
of the cap. See fig 6.
Once the cap has been snapped back onto the top of the unit, rescrew the 3 screws
to hold the cap on.
Fig. 6:

EdgeStar AP310SS Specifications

General

Brand	EdgeStar
Model	AP310SS
Category	Air Conditioner
Language	English
