EdgeStar AP550Z Troubleshooting And Reconnecting Wires

Step C.
Pull the panel down and
off the unit
Step B.
Remove these two
screws.
6. Locate the “compressor capacitor”. It is a silver cylinder that is about 4”
long.
Make sure that the unit is not plugged in prior to touching any wires
Compressor
capacitor
