2.0 MECHANICAL INTERFACE 2-2
4205 MAGNETOMETER INTERFACE 0021770_REV_A
Figure 2-2: Connection Setup for Marine Magnetics SeaSPY Magnetometer
Figure 2-3: Connection Assembly for SeaSPY Magnetometer
Anchor Tow
cable, 2
points, with
cable
tie
